230 V a.c./d.c. (5-250 V a.c./d.c.), 3 A DO821 | 3BSE013250R1 Digital Output Module

Name: 230 V a.c./d.c. (5-250 V a.c./d.c.), 3 A DO821 | 3BSE013250R1 Digital Output Module
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: DO821
Price: 210.00 USD
Availability: InStock

Marchio:	ABB
Numero di modello:	DO821
MOQ:	1
prezzo:	Negotiations

Informazioni dettagliate

Descrizione del prodotto

Informazioni dettagliate

Luogo di origine:

Svizzera

Tensione di isolamento valutato potenziometro:

50V

Tensione di prova dielettrica:

500VAC

Consumo corrente +5 V Modulebus:

70 mA

Dissipazione del potere:

1.6W

Imballaggi particolari:

Nuova scatola originale+

Evidenziare:

230V AC/DC digital output module

3A DO821 output module

ESP controller digital module

Descrizione del prodotto

230 V a.c./d.c. (5-250 V a.c./d.c.), 3 A DO821 | 3BSE013250R1 Digital Output Module

Product Attributes

Attribute	Value
Potentiometer Rated Insulation Voltage	50V
Dielectric Test Voltage	500VAC
Current Consumption +5 V Modulebus	70mA
Power Dissipation	1.6W

Product Description

230 V a.c./d.c. (5-250 V a.c./d.c.), 3 A DO821 | 3BSE013250R1 Digital Output Module

General Info

Type	Digital Output
Signal specification	230 V a.c./d.c. (5-250 V a.c./d.c.), 3 A
Article number	3BSE013250R1
Number of channels	8
Signal type	Relay (NC)
HART	No
SOE	No
Redundancy	No
High integrity	No
Intrinsic safety	No
Mechanics	S800

Detailed Data

Isolation	Individually isolated, channel-to-channel and to circuit common
Current limiting	Can be current limited by the MTU
Maximum field cable length	600 meters (656 yards)
Rated insulation voltage	250 V
Dielectric test voltage	2000 V a.c.
Power dissipation	Typ. 2.9 W
Current consumption +5 V Modulebus	60 mA
Current consumption +24 V Modulebus	140 mA
Current consumption +24 V external	0

Environment and Certification

CE mark	Yes
Electrical safety	IEC 61131-2, UL 508
Hazardous Location	-
Marine certification	ABS, BV, DNV-GL, LR, RS, CCS
Protection rating	IP20 according to IEC 60529
Corrosive atmosphere ISA-S71.04	G3
Climatic operating conditions	0 to +55 °C (Storage -40 to +70 °C), RH=5 to 95 % no condensation, IEC/EN 61131-2
Pollution degree	Degree 2, IEC 60664-1
Mechanical operating conditions	IEC/EN 61131-2
EMC	EN 61000-6-4, EN 61000-6-2
Overvoltage categories	IEC/EN 60664-1, EN 50178
Equipment class	Class I according to IEC 61140; (earth protected)
Max ambient temperature	55 °C (131 °F), for vertical mounting in compact MTU 40 °C (104 °F)
RoHS compliance	EN 50581:2012
WEEE compliance	DIRECTIVE/2012/19/EU

Diagnostics

Front LED's	F(ault), R(un), W(arning), O(SP), Channel 1-8 Status
Supervision	24 / 12 V Relay power converter monitor
Status indication of supervision	Module Error, Module Warning, Channel error
